Type A grid panel selection table
Board length(mm)：2680
Board width(mm)：2680
Plate thickness(mm):107
Main frame:C100*40*15*2.5
Main rib：Double C 80*40*15*2.0
Frame border:C100*40*15*2.5
Standard value of the plate self-weight(kN/㎡):0.61
Allowance for uniformly distributed additional load standard value(Qk):1.2
Allow for the design value of additional uniformly distributed loads(k):1.56
